Scaffolding alarm system
Scaffolding alarm system with Smartphone Management - Simple installation - Reliable - Unsabotageable
Scaffolding alarm system with Smartphone Management - Simple installation - Reliable - Unsabotageable
The SCAFFOLDING SICURI system has been specifically developed to meet the growing demand for a solution for the protection of scaffolding and scaffolding.
Simple to install and calibrate, the system is particularly advantageous due to the wide coverage and its almost total invisibility.
Intended for the protection of scaffolding and scaffolding, PONTEGGI SICURI can be programmed via SMS or dedicated software (CTCSOFT) and is able to cover up to 200 meters of surface ensuring a wide range of applications; from the small house to the condominium.
Principle of operation
The system is based on the trampling analysis of the walkways using a sensor cable (FLEXCVPKIT), which can be clamped or passed through the scaffolding ducts.
SAFE SCAFFOLDING thanks to hardware and software filters and a simple calibration easily discriminates against false alarms deriving from environmental conditions, guaranteeing prompt and reliable detection. Equipped with GSM module and built-in siren, the control unit can be inserted
and deactivated by calling at no cost from authorized numbers, which can also receive alarm and system tampering notifications via SMS.
Some technical data:
- PRODUCT CODE: FLCENKITP
POWER SUPPLY: 12VDC
ABSORPTION: 10mA (40 SMS sending)
WORKING TEMPERATURE: -40°C / +80°C
MAX HUMIDITY AT 35°C: 98%
ALARM OUTPUT: Relay contact, SMS
TAMPER OUTPUT: Relay contact, SMS
DIMENSIONS (L X H X D): 250 x 300 x 160 mm.
HOUSING: IP65
WEIGHT: (APPROXIMATELY) 6,0 Kg.
SYSTEM ARMING NOTIFICATION NUMBERS: 4
ALARM-TAMPER NOTIFICATION NUMBERS: 4
ARM-DISARM NUMBERS. SYSTEM: 54
SURVIVAL MESSAGE: YES
INSUFFICIENT POWER NOTIFICATION: YES
- PRODUCT CODE: FLEXCVPKIT
MAXIMUM CABLE LENGTH: 200 m. for analyzer
SECTION DIAMETER: 10mm
CABLE CUT DETECTION: YES
FLEXTR IMPEDANCE: 220 KOhm
FLEXCN DIMENSIONS: 42 x 53 x 27 mm.
High resistance to distortion and UV rays
